Our core drill bits are specially designed to efficiently obtain core samples from underground formations. They use a variety of cutting elements, including carbide, polycrystalline diamond compact (PDC), and natural diamond. These bits deliver fast drilling rates and high footage in soft to medium-hard formations, making them ideal for geological exploration, mining, and oil and gas drilling.
Based in the Hebei Provincet, a region known for significantly contributing to land-based drilling, we leverage local manufacturing expertise to supply high-quality, API-compliant core drill bits at competitive prices. Our core drill bits provide a cost-effective alternative to more expensive Western brands while meeting international standards.
What is a Core Drill Bit?
Core drill bits are used to extract rock core samples during drilling. The core obtained allows for detailed analysis of the formation’s geological structure, rock properties, mineral composition, and hydrocarbon content. As the bit rotates, cutting elements crush the rock, and the drilling fluid carries out the cuttings while the intact core remains inside the core barrel for later retrieval.
Core Drill Bit Models and Specifications (Examples):
| Model | Cutting Element Type | Cutter Diameter | Blade Count | Recommended Formation | Compatible Tools |
|---|---|---|---|---|---|
| HC143 | Carbide | – | 5 | Soft | Coring tools for soft formations |
| PDC143 | PDC | 13 mm | 5 | Soft | Coring tools for soft formations |
| PDC136 | PDC | 13 mm | – | Medium-Hard | Coring tools for hard formations |
| PDC037 | PDC | 8 mm | 6 | Medium-Hard | Coring tools for hard formations |
| PDC038 | PDC | 8 mm | 8 | Medium-Hard | Coring tools for hard formations |
| PC536 | Polycrystalline Diamond | – | – | Medium-Hard | Coring tools for hard formations |
| ND938 | Natural Diamond | – | – | Very Hard | Coring tools for extremely hard formations |
| IE536 | Impregnated Elements | – | – | Very Hard | Coring tools for extremely hard formations |
Our range of core bits includes various models designed to handle different formation types, from soft to extremely hard. Each model is engineered for specific drilling conditions to optimize drilling performance and core recovery.
Contact us for more details on pricing and customizations.
